€ 1'329.00
21 in stock
| Category: General | |
|---|---|
| Processor model | Intel Core i7 (14. Gen.) 14700 / 28 MB Intel Smart Cache, max. Turbo-Frequency 5.4 GHz) |
| Operating system | Windows 11 Pro |
| Category: Processor | |
| Processor family | Core i7 |
| Processor cores | 20-Core |
| Processor socket | FCLGA1700 Socket |
| Number of processors | 1 |
| Category: Memory | |
| Internal memory | 16 |
| Memory layout (slots x size) | 1 x 16 GB |
| Maximum internal memory | 128 |
| Memory clock speed | PC5600 |
| Internal memory type | DDR5 SDRAM |
| Memory slots | 4 |
| Category: Storage | |
| Total storage capacity | 1 |
| HDD interface | 2x M.2 (Key M) 2280/2260/2242, PCIe 4.0 x4 mode, 4x SATA 6Gb/s ports ¦ Supports SATA Raid, no NVMe Raid |
| RAID levels | RAID 0 ¦ RAID 1 ¦ RAID 10 |
| SSD interface | PCIe 4.0 |
| SSD capacity | 1 |
| HDD capacity | 1 x 1 TB – SSD |
| Number of storage drives supported | 4x SATA 6Gb/s ¦ 2x M.2 (2280) PCIe/NVMe 4.0 x4 |
| Storage media | SSD M.2 |
| Category: Performance | |
| Series | Business |
| Nivel de ruido | 24,0 dB (Idle-Mode) |
| Audio output channels | 8-channel |
| Motherboard chipset | Intel B760 |
| Category: Design | |
| Chassis type | Mid tower |
| Certification | ISO 9001, Assembled in Germany ¦ Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC |
| Keyboard form factor | TERRA Keyboard German Layout |
| Category: Keyboard | |
| Keyboard language | German |
| Connectivity technology | Wired |
| Device interface | USB |
| Category: Technical details | |
| Localization | German |
| Category: Packaging content | |
| Included Accessories | Quick Start Guide, Powercord EU |
| Category: Expansion slots | |
| Expansion slots | 1x PCIe 4.0/3.0 x16 slot ¦ 2x PCIe 3.0 x1 |
| Category: Weight & dimensions | |
| Height | 43.5 |
| Width | 18 |
| Depth | 42 |
| Weight | 8 |
| Category: Other features | |
| Number of drive bays | 1 front – 13.3 cm ( 5.25" ) ¦ 1 front – 8.9 cm ( 3.5" ) ¦ 2 internal – 8.9 cm ( 3.5"/ 2.5" with adapter)¦1 internal 6.4 cm (for 2.5" SSD) |
| Interface | 4x USB 3.2 Gen1 ports Type-A (2x front), 2x USB 2.0 ports ¦ 1x LAN RJ-45, 3x Audio jacks, 2x PS/2 ¦ Option: 2x COM, 1x LPT, 1x TPM module |
| Compatible operating systems | Windows 10, Windows 11 |
| Motherboard manufacturer | ASUS PRO B760M-C-CSM ¦ 24-7 ready |
| Cooling type | TERRA Silent Heatpipe Cooler |
| Compliance industry standards | CE, ISO 9001, Assembled in Germany ¦Compatibility: PC2001, SMBios (DMI) 2.3, PCI 2.2,WFM 2.0, EnergyStar, EN60950, EN55022,EN55024, EN61000-3-2/3, 89/336/ECC |
| Special features | TPM 2.0 ¦ Secure Boot ¦ Windows Autopilot ready ¦ 2x USB 3.2 Gen1 Typ A + Audio in Front |
| Category: Mouse | |
| Mouse included | Terra Mouse Corded |
| Category: Graphics | |
| On-board graphics adapter memory | Dynamisch |
| On-board graphics adapter maximum resolution | DisplayPort 1.2 max. 4096 x 2304@60Hz ¦ HDMI 2.1 max. 4096 x 2160@60Hz ¦ D-Sub (VGA) max. 1920 x 1200@60Hz |
| Graphics card | Intel UHD Graphics 770 |
| On-board graphics card model | Intel UHD Graphics 770 |
| Graphics adapter ports | 1x HDMI, 2x DP (Display Port), 1x VGA ¦ Supports Quad-Monitoring |
| Category: Power | |
| Maximum input power | 400 Watt |
| Nominal power | Ø 20 Watt Idle-Mode ¦ Ø 77 kWh a year (TEC = Typical Energy Consumption) ¦ Further information regarding Energy consumption see http://www.wortmann.de/green and/ or Quicklinks for this product (if available) |
| AC adapter input voltage | AC 230V ( 50 Hz ) |
| Category: Operational conditions | |
| Operating temperature (T-T) | 0° – 35° C |
| Maximum operating temperature range (T-T) | 32 °C |
| Recommended humidity operating range | 10 – 75% (non-condensing) |
| Category: Network | |
| Ethernet LAN | RJ45 |
| LAN controller | 1x Intel 1Gb Ethernet, WOL by PME, PXE |
| Data link protocols | Ethernet ¦ Fast Ethernet ¦ Gigabit Ethernet |
| Category: Optical drive | |
| Optical drive type | w/o ODD |
| Category: Input device | |
| Movement detection technology | Optical |
| Category: Software | |
| Pre-installed software | 1 month trial version for new Microsoft® 365 user |
